Two Die Head Blown Film Extrusion

Two Die Head Blown Film Extrusion

Double Die Head Blown Film Extrusion  Characteristics:
Both the cylinder and the screw of the extruder are made of high quality alloy steel through nitration and precision finishing with the best hardness and corrosion resistance.,Scientifically designed,this machine set has two heads for one extruder with such advantages as increasing production capacity,saving energy,labour and workshop area,etc.

Use:
This Double Die Head Blown Film Extrusion is used for blowing Low-density polyethylene(LDPE)and high-densitypolyethyene(HDPE)plastic film to make various vest bags and flat-rim bags which have been widely used for packing in the food industry,garment industry and textile industry,etc.


Technical Parameter:

Model

SJ65-FM600

SJ70-FM700

SJ75-FM800

Screw Diameter

65mm

70mm

75mm

Screw Ratio

28:1

28:1

28:1

Screw Speed

10-110r/min

10-110r/min

10-110r/min

Max.Output

50kg/h

70kg/h

90kg/h

Max.Folding Width of Film

550mm*2

650mm*2

750mm*2

Single-sided Thickness of Film

0.006-0.10mm

0.006-0.10mm

0.006-0.10mm

Power of Main Motor

18.5-22Kw

22-30Kw

37Kw

Total Power

40Kw

55Kw

70Kw

Weight of Machine

3000kg

3800kg

4500kg

Measure (m)

4.8*2.2*3.8

5*2.4*4

5.2*2.6*4.2
